Quantentech QJR Series Industrial UAV Electric Drives

- Dynamically reconfigurable multi-phase motors: 100% torque & power density increase, 40% weight reduction

- OD 85/120/180mm, 3–30kW peak power output

- 85 mm model to replace 100–120 mm standard motors

- 120 mm model to replace 150–200 mm conventional motors

- Miniature GaN high-frequency ESCs with fast response

- 7-phase drive system, fault-tolerant & highly reliable

- Ample torque reserve, short-duration high-power operation, superior wind resistance

QJR8515 Motor Parameters

- OD: 85 mm | Stack Height: 15 mm

- Peak Torque: 15 Nm

- Short-Time Torque: ＞35 Nm
